Kontron Microserver

µDARC Microserver

The Kontron µDARC microserver is an ultra-rugged, compact, and resilient mobile microserver designed for applications in harsh environments. Powered by a high-efficiency NXP Arm® i.MX8X quad-core processor, it delivers robust computing performance with ultra-low power consumption.Featuring a wide range of I/O options, µDARC ensures seamless connectivity and real-time data processing at the tactical edge. Its…

  • Ultra-rugged mobile microserver
  • Quad-Core NXP Arm® Cortex-A35 processor – i.MX8X
  • Ultra-compact
  • Robust and secure design with cybersecurity chain of trust
  • MIL-STD-810G, STANAG 4370 (AECTP 300, 400, 500), MIL-STD-461G
  • CE, REACH / RoHS certified
  • Long-term support, ITAR-free
  • Cryptographic key management memory
  • Linux Yocto 4.0 OS
  • Build-to-order configured to your requirements

Critical edge node

With a sealed IP67 enclosure and a weight of only 735 grams, the µDARC microserver is engineered for deployment on soldiers, UAVs/UGVs, and mobile command systems. It processes sensor data (LiDAR, GPS, cameras) in real time – even under mission-critical conditions.

Kontron Microserver
Kontron Microserver

Secure data handling

Equipped with built-in cybersecurity features and multiple connectivity options, the µDARC microserver ensures secure data collection, processing, and transmission at the tactical edge. The microserver is a reliable solution for network-centric warfare and secure field-deployed computing applications.

Product features

Kontron Microserver

MIL-STD-810G & STANAG 4370 certified

Kontron Microserver

Ultra-rugged, IP67-rated enclosure for harsh environments

Specifications

Model Type

Ultra-rugged microserver

Form Factor

Small Form Factor (SFF)

Cooling

Fanless

Ingress Protection

IP67

Environment

Operating temperature -19 °C to +49 °C
Storage temperature -21 °C to +71 °C

Certification

CE, REACH / RoHS
MIL-STD-810G
MIL-STD-461G
STANAG 4370 (AECTP 300, 400, 500)

Management Software

U-Boot

Processor

Low Power i.MX8X Series processor
Quad-core Arm® Cortex-A35, one Cortex-M4F
GPU, VPU

RAM

3GB DDR4

Storage

8 GB eMMC (optional up to 32 GB pSLC / 64 GB MLC)

Front Input / Output

3 × USB 2.0 (one OTG)
1 × Gigabit Ethernet (1000BASE-T), optional additional port
2 × EIA-232 with flow control (TXD, RXD, RTS, CTS)
Optional Wi-Fi IEEE802.11 b/g/n with integrated antenna
Optional Bluetooth / BLE 4.2 with integrated antenna

Special Function

Cryptographic keys management memory

Operating System

Linux Yocto 4.0

Power Supply

12 VDC nominal Batteries Type 1: 14.5 V; Type 2: 10.2 V nominal

Power Consumption

Less than 5W

Dimension and Weight

Dimension H 159.2 × W 111 × D 38.4 mm
Weight 735g

Warranty and After Sales Support

Standard 1 year (option for 3 years)
