Blue Line Vehicle PC VPC-2000

The VPC-2000 is a durable in-vehicle computer available in three versatile models.

Fanless and rugged in-vehicle computer
Intel Elkhart Lake Atom processor
E-Mark certified and EN 50155 EMC compliant
4 x PoE+ GbE ports via M12 x-coded connectors

1 x front-accessible 2.5” HDD tray and 1 x M.2 2280
1 x M.2 for 4G / 5G mobile broadband
2 x mPCIe sockets for WIFI / CAN / GNSS modules
+8 to 35V wide-range DC input with ignition power control
Wide temp -40°C to 70°C
Build-to-order configured to your requirements

Model 2

Model 2 features an embedded SuperCAP UPS, ensuring resilience against power interruptions and voltage fluctuations for a secure shutdown during power loss.

Model 3

Model 3 is equipped with a Cassette module, enabling an additional generation 3 x 2 PCIe slot for accommodating an AI accelerator module with a customized thermal solution.

This configuration transforms the VPC-2000 into a fanless GPU computer suitable for intelligent video analytics or a data logger with perception.

Designed to thrive in challenging electrical environments, the VPC-2000 is an ideal solution for off-highway applications such as trucks, cargo vehicles, and rolling stock.

Product features

Compact

AI-ready expandability

Specifications

Download datasheet

Vehicle PC

Compact

Aluminium

Fanless

Operating Temperature -40°C to 70°C (with wide temp MEM / SSD)

Storage Temperature -40°C to 85°C

Humidity 10% to 90%, non-condensing

Vibration operating MIL-STD-810G, method 514.7, category 4 IEC61373:2010, category 1, class B body mounted (part of EN50155)

Shock operating MIL-STD-810G, method 516.7, procedure I IEC61373:2010, category 1, class B body mounted (part of EN50155)

Model 1, 2 & 3 CE/FCC class A according to EN 55032 & EN 5503

Model 1 & 3 E-Mark certified and EN 50155 EMC compliant

Intel Elkhart Lake Atom x6425E quad-core 2.0GHz / 3.0GHz (12W TDP)

SoC

Up to 32 GB, 1 x 260-pin DDR4-3200 SDRAM socket

1 x M.2 2280 M key (SATA interface only) socket for SATA SSD installation

1 x 2.5″ front-accessible tray for HDD / SSD installation (up to 15mm height)

1 x Power switch

1 x Audio 3.5 mm jack for mic-in and speaker-out isolated

1 x USB 3.1 generation 1 type A ports with screw-lock

2 x USB 2.0 type A ports with screw-lock

1 x RS-422/485 (COM2) or 3 x 3-wire RS-232 ports (COM2 / 3 / 4)

1 x Isolated RS-485 port with 15 kV ESD protection (COM1)

1 x DVI-I connector for video port

LED indicators (IGN, WDT, HDD, PWR)

1 x 3-pin pluggable terminal block for +8 to 35V DC input

1 x 3-pin pluggable terminal block for remote ON/OFF control and PWR LED output

4 x IEEE 802.3at (25.5W) gigabit PoE+ ports by Intel i210 via M12 x-coded connectors

1 x DB15 port for 4-CH isolated DI and 4-CH isolated DO

Model 1, 2 & 3 1 x Full-size mini PCI express socket with PCIe and USB 2.0 signal

1 x Full-size mini PCI express socket with USB 2.0 signal M.2 B key

1 x M.2 3042/3052 B key (USB 3.1 + USB 2.0) for 4G/5G module with dual internal micro SIM socket

Model 3 1 x Internal PCIe x2 gen3 in 4-lane slot (signal in Cassette)

Windows 10 / 11

Windows 10 IoT Enterprice

Linux

Model 1, 2 & 3 1 x 3-pin pluggable terminal block for +8 to 35V DC input with built-in ignition power control (IGN/GND/V+)

Model 2 Internal SuperCAP power backup w/capacity for 2500 watt-second

TBD

Model 1 H 58 x W 205 x D 155mm 1.9kg (gross weight NNkg)

Model 2 H 86 x W 205 x D 155mm 2.5kg (gross weight NNkg)

Model 3 H 86 x W 205 x D 155mm 2.3kg (gross weight NNkg)

Damping bracket (default)

Wall-mount (optional)

Damping bracket kit

Model 2 built-in SuperCAP UPS

Model 3 single-slot PCIe Cassette

120W AC/DC power adapter 20V/6A; 18AWG/120cm; cord end terminals for terminal block, operating temperature: -30 to 70°C

160W AC-DC power adapter 20V/8A; 18AWG/120cm; cord end terminals for terminal block, operating temperature: -30 to 70°C

Wall mounting kit

GPS module + antenna kit

WIFI / Bluetooth module + antenna kit

4G / 5G / LTE module + antenna kit

CAN Port

Standard 1 year (option for 3 years)
