Blue Line IGPU-6000

Blue Line IGPU-6000 is a high-performance GPU solution designed specifically for AI and deep learning inference platforms, offering industrial-grade reliability in a compact chassis. Built for demanding environments requiring consistent performance and extended lifecycle support.

Extended product life cycle
Short-depth industrial chassis
4U rack mount chassis
3 x double slot GPU / FPGA / VPU

Intel XEON-W CPU
Windows 7 / 8 /10 / Linux
Build-to-order configured to your requirements

Download datasheet

Advanced AI computing

The IGPU-6000 delivers exceptional processing power through its triple GPU configuration, featuring Intel Xeon Skylake-W series processors and support for up to 512GB DDR4 memory.

Robust construction

The robust cooling system with dust filters and heavy-duty cold rolled steel construction ensures reliable 24/7 operation in industrial environments.

Its comprehensive connectivity options include dual Ethernet ports, multiple USB interfaces, and extensive expansion capabilities.

Product features

Short-depth industrial chassis

High-performance GPU inference platform

Specifications

Download datasheet

GPU

4U rackmount

Heavy duty cold rolled steel

Two 120 x 120 x 38mm 4pin PWM front fan (max speed 4000 RPM) for GPU / CPU air cool (with dust filter)

Operating temperature 0°C to +40°C

CPU Intel Xeon Skylake-W series supported (Max 140W)

GPU / FPGA / VPU 3 GPU (max 250W pr. unit)

Intel C422

8 x 288pin DDR4 Registered ECC/ECC LRDIMM 2666MHz
Supports up to 512GB

3 x 5.25” drive bay

1 x 3.5″ drive bay

(Option for internal 2.5″ / 3.5″ HDD / SSD)

2 x M.2 NVMe SSD – 22110

1 x RJ-45 GbE Intel I210-AT Ethernet Controller

1 x RJ-45 5GbE Aquantia LAN chip AQC108 Ethernet Controller

1 x VGA

6 USB 2.0 ports (2 rear + 4 headers)

6 USB 3.0 ports (4 rear + 2 headers)

2 USB 3.1 ports (2 Type A)

3 x PCIe 3.0 x16 (8/16/16 (Skylake-W 48 lanes))

1 x PCIe 3.0 x4

2 x M.2 Interface PCIe 3.0 x4

Windows 7 / 8 / 10

Windows Embedded 7 / 8

Windows 10 IoT Enterprise

Linux

1200W, ATX, 120mm Fan, Full Range input, 80 Plus Gold

19″ H 177 x W 427 x D 510mm

Rackmount

Rackmount kit

2.0 mtr. schuko EU to C19 Female 230V power cable

Rack mount rail kit

Standard 1 year (option for 3 years)

1802

From setup to delivery

Reduce cost and time spending with our global partner model based on your specific requirements. Let Blue Line take responsibility for delivery on time.

Blue Line’s ultimate goal is to help our customers get peace of mind by handling all relevant details such as securing the right configuration, software setup, mounting, packaging, labeling etc. Ask for references from your industry.
